GRAY CAST İRON
Solid cast iron obtained from high furnaces melting in ergitilerek previously prepared mold, taking the shape of the mold with the spill into the solidification is achieved as a result of.
- Mechanical properties of Nodular graphite Cast Iron cast iron Casting is lower than.
- These features can be added to elements, and elevations.
- As to old system cast iron is shown between G18 - GG35
| GREY CAST IRON MECHANICAL AND PHISCAL PROPERTIES |
| MATERIALS NAME |
EN-GJL-150 Cr Cu HC |
EN-GJL-150 |
EN-GJL-200 |
EN-GJL-250 |
EN-GJL-300 |
| CODE |
- |
EN-JL 1020 |
EN-JL 1030 |
EN-JL 1040 |
EN-JL 1050 |
| TENSILE STRENGTH Rm, Mpa (min.) |
130 |
135 |
180 |
225 |
270 |
| HARDNESS HB |
150 - 210 |
135 - 190 |
145 - 215 |
170 - 235 |
190 - 251 |
| DENSITY ρ, t/m3 |
7,1 |
7,1 |
7,15 |
7,2 |
7,25 |
| STRUCTURE |
perlit /ferrit |
perlit /ferrit |
perlit /ferrit |
perlit |
perlit |
| |
|
|
|
|
|
| NOTE 1: 1 Mpa = 1 N/mm2 |
|
|
|
|
|
| |
